Rigol RSA5032 3.2GHz Real-Time Spectrum Analyser
Rigol RSA5032 3.2GHz Real-Time Spectrum Analyser

Rigol RSA5032





Alternative Views:


Rigol RSA5032
3.2GHz Real-Time Spectrum Analyser

Our Price: £6,241.20 (7,489.44 inc VAT)
Free Software Options Bundle (£1,532 Value)






Quantity in our UK Stock.:
(Out of Stock-Click to be notified when in stock)


Availability: Stock models DELIVERED NEXT WORKING DAY (UK Only) for orders placed before 15:00 (Mon - Fri)
Product Code: RSA5032



The following items are included FREE OF CHARGE with this product:

Description Specification Documents, Software & Videos


Free Software Options Bundle (£1,532 Value!)

Purchase any RSA3000 Series Real-Time Spectrum Analyser to receive the RSA5000-B40 and RSA5000-PA licences free of charge!
Valid Until 30/9/2020

Rigol RSA5000 series real-time spectrum analysers combines the power of a high-performance conventional spectrum analyser with superior real-time performance, unmatched in this product category. Available in 3.2GHz and 6.5GHz models, all RSA5000 series analysers provide a resolution bandwidth (RBW) down to 1Hz, a noise floor as low as -165dBm/Hz and a full span sweep as fast as 1ms. In addition, the analyser features up to 40MHz of real-time bandwidth (optional), a minimum probability of intercept (POI) of 7.45µs, 7-rich visualisation modes and powerful triggering capability. The Rigol RSA5000 series is a complete analysis package for engineers developing and integrating todays wireless technologies utilising complex and dynamic modulation schemes.

For further information, please refer to the 'SPECIFICATION' and 'DOCUMENTS, SOFTWARE & VIDEOS' tabs, above.

An overview of all Rigol spectrum analysers can be found HERE.



Click image to enlarge

Features
  • Displayed average noise level (DANL): <-165dBm (typical) (With Optional Pre-Amp On)
  • Phase noise: <-108dBc/Hz @ 10kHz (typical, f = 1GHz)
  • Level measurement uncertainty: <0.8dB
  • Built-in tracking generator ('-TG' models only)
  • Minimum RBW: 1Hz
  • EMC filter and quasi-peak detector
  • Various measurement functions
  • Multiple measurement modes
  • Up to 40MHz real-time analysis bandwidth
  • Multiple trigger modes and trigger masks
  • Density, spectrogram, and other display modes
  • 10.1'' capacitive multi-touch screen, supporting touch gestures
  • USB, LAN, HDMI and other communication and display interfaces
  • Supplied with... Power cable & quick guide
  • Options include... Preamplifier, high-stability reference, 40MHz real-time / analysis bandwidth, advanced measurement kit
  • Optional PC software... Ultra Spectrum, S1210 EMI Pre-Compliance Test
  • Accessories include... Rack mount kit
