Micsig CP2100A AC/DC Current Probe

(1 customer review)

£214.16 (£256.99 inc VAT)

5+ In UK Stock

Availability: Stock models delivered next working day (UK only) for orders placed before 16:30 (Mon - Fri)

Free Shipping Price Match Guarantee
SKU: CP2100A Categories: ,

Description


The Micsig CP2100A is an AC/DC current probe with a small yet compact design. It uses a standard BNC interface for oscilloscopes or a multi-connector for adapters. The maximum current that can be measured is 100Apk and the bandwidth is DC ~ 800kHz. The probe has two optional ranges of 10A and 100A.

  • Bandwidth up to 800kHz
  • Powered by USB, making measurement easier
  • Both automatic and manual zero adjustments are available
  • Maximum measurable current, 100Apk, 70.7Arms (DC+ACpk)

Features:

  • Bandwidth: DC~800kHz
  • Rise Time: ≤583ns
  • Ranges: 10A/100A
  • Output Sensitivity: 0.1V/A (10A), 0.01V/A (100A)
  • Signal Delay: <150ns (10A), <200ns (100A)
  • Current Measurement Range: 50mA~10Apk (10A), 1A~100Apk (100A)
  • Maximum Measurable Current: 100Apk, 70.7Arms (DC+ACpk), 200Apk-pk, 70.7Arms (AC)
  • Maximum Working Voltage: CAT III = 300V, CAT II = 600V
  • Maximum Float Voltage: CAT III = 300V, CAT II = 600V
  • Maximum Conductor Diameter: 13mm
  • Overload Indication: The buzzer beeping, the button light flashing
  • Power Supply: DC 5V
  • Probe Head Size: 11*6.1*2.5cm
  • Control Box Size: 10.8*5.6*2.6cm

Documentation

1 review for Micsig CP2100A AC/DC Current Probe

  1. santiagogoldaraz (verified owner)

    A great current probe at an excellent price. Quality is very good, and fast shipping time. Easy to read current smaller than 50mA but offset needs to be calibrated for better readings.
