Sale!
Rigol DP822A Linear DC Power Supply (20V/5A & 5V/15A)
Original price was: £797.00.£605.00Current price is: £605.00. (£726.00 inc. VAT) (£726.00 inc VAT)
Out of stock
Availability: Stock models delivered next working day (UK only) for orders placed before 16:30 (Mon - Fri)
Rigol DP800 User Guide | DC Output (0°C to 40°C) | ||||
|---|---|---|---|---|
| Model | DP811A | DP821A | DP831A | DP832A |
| Voltage/Current Rating | Range 1: 0 to 20V/0 to 10A Range 2: 0 to 40V/0 to 5A | CH1: 0 to 60V/0 to 1A CH2: 0 to 8V/0 to 10A | CH1: 0 to 8V/0 to 5A CH2: 0 to 30V/0 to 2A CH3: 0 to -30V/0 to 2A | CH1: 0 to 30V/0 to 3A CH2: 0 to 30V/0 to 3A CH3: 0 to 5V/0 to 3A |
| OVP/OCP | Range 1: 1mV to 22V/0.1mA to 11A Range 2: 1mV to 44V/0.1mA to 5.5A | CH1: 1mV to 66V/0.1mA to 1.1A CH2: 1mV to 8.8V/1mA to 11A | CH1: 1mV to 8.8V/0.1mA to 5.5A CH2: 1mV to 33V/0.1mA to 2.2A CH3: -1mV to -33V/0.1mA to 2.2A | CH1: 1mV to 33V/1mA to 3.3A CH2: 1mV to 33V/1mA to 3.3A CH3: 1mV to 5.5V/1mA to 3.3A |
| Load Regulation Rate ± (Output Percentage + Offset) | ||||
| Voltage | <0.01% + 2mV | <0.01% + 2mV | <0.01% + 2mV | <0.01% + 2mV |
| Current | <0.01% + 250μA | <0.01% + 250μA | <0.01% + 250μA | <0.01% + 250μA |
| Linear Regulation Rate ± (Output Percentage + Offset) | ||||
| Voltage | <0.01% + 2mV | <0.01% + 2mV | <0.01% + 2mV | <0.01% + 2mV |
| Current | <0.01% + 250μA | <0.01% + 250μA | <0.01% + 250μA | <0.01% + 250μA |
| Ripples and Noise (20Hz to 20MHz) | ||||
| Voltage | DP832A/DP831A/DP821A: <350μVrms/2mVpp DP811A: <350μVrms/3mVpp | DP832A/DP831A/DP821A: <350μVrms/2mVpp DP811A: <350μVrms/3mVpp | DP832A/DP831A/DP821A: <350μVrms/2mVpp DP811A: <350μVrms/3mVpp | DP832A/DP831A/DP821A: <350μVrms/2mVpp DP811A: <350μVrms/3mVpp |
| Current | <2mArms | <2mArms | <2mArms | <2mArms |
| Transient Response Time | ||||
| Transient Response Time | Less than 50μs for output voltage to recover to within 15mV following a change in output current from full load to half load or vice versa. | Less than 50μs for output voltage to recover to within 15mV following a change in output current from full load to half load or vice versa. | Less than 50μs for output voltage to recover to within 15mV following a change in output current from full load to half load or vice versa. | Less than 50μs for output voltage to recover to within 15mV following a change in output current from full load to half load or vice versa. |
| Command Processing Time | ||||
| Command Processing Time | <118ms | <118ms | <118ms | <118ms |
Note* Specifications are liable to change. For the full list of Specifications, please see the products datasheet located under the ‘Documentation’ tab.
