Rigol DS2072A 70MHz Digital Oscilloscope
Rigol DS2072A Digital Oscilloscope

Rigol DS2072A





Alternative Views:


Rigol DS2072A
70MHz Digital Oscilloscope

Our Price: £641.00 (769.20 inc VAT)

Latest Firmware Fitted read more



Quantity in our UK Stock.:5

Availability: Stock models DELIVERED NEXT WORKING DAY (UK only) for orders placed before 15:00 (Mon. - Fri.).
Product Code: DS2072A
Qty:




The following items are included FREE OF CHARGE with this product:

Description Specification Documents, Software & Videos


PROMOTION = FREE Software Options Bundle (BND-MSO/DS2000A)
Buy this Rigol MSO/DS2000A series oscilloscope and get ALL software options
(deeper memory, advanced trigger functions, serial-bus decoding & CAN bus analysis) for FREE!
Only whilst stock lasts.


The Rigol DS2072A is a multi-functional high performance digital oscilloscope. Standard features include - Sensitivity down to 500μV/div, record, replay & analysis functions, selectable 50Ω input impedance and 8" WVGA display with 256 grading levels. Furthermore, it possesses a variety of trigger functions, decoding functions, connectivity options, mathematical operations including FFT, automatic waveform measurement parameters with statistics, a pass / fail test and a built-in help system. A two channel 25MHz function / arbitrary waveform generator is included on '-S' models. The Rigol DS2072A is a versatile instrument that offers useful performance and features at a very competitive price.

For further information, please refer to the ' Specification' and 'Documents, Software & Videos' tabs, above.

An overview of all Rigol digital oscilloscopes can be found HERE.

This Rigol oscilloscope is also available with...

  • A built-in 2-channel function / arbitrary waveform generator (DS2072A-S).
  • A built-in logic analyser (MSO2072A).
  • A built-in logic analyser and a built-in 2-channel function / arbitrary waveform generator (MSO2072A-S).


Click image to enlarge

Features
  • 70MHz bandwidth, 2 channels
  • Maximum sample rate 2GSa/s
  • Vertical scale 500μV/div to 10V/div
  • Selectable 50Ω input impedance
  • Memory depth up to 14Mpts (56Mpts optional)
  • Innovative "UltraVision" technology
  • Up to 50,000wfms/s waveform capture rate
  • Up to 65,000 frames real-time waveform record, replay & analysis functions
  • 8" WVGA (800x480) TFT LCD display, 256 intensity grading levels
  • Up to 17-off trigger functions, including various protocol triggers
  • Auto measurement of 29 waveform parameters, with statistics
  • Built-in FFT with a choice of window functions
  • Pass/fail test function
  • Various waveform math functions
  • Supports internal and external storage of instrument settings, waveforms, screen images and parameters
  • PictBridge printer support
  • Built-in help facility
  • Connectivity: USB Host & Device, LAN(LXI), AUX Output, (USB-GPIB, optional)
  • Supplied with... 2-off passive probes (350MHz), USB cable, UK & European mains leads, quick guide
  • Options include... Deeper memory, advanced trigger functions, RS232/I2C/SPI decoding kit, CAN analysis kit, rack mount kit, soft carry bag, RCL standard calibration, RCL UKAS calibration
