Siglent N-SMA-6L RF Cable
The Siglent N-SMA-6L is a 70 cm, 50 Ω RF cable with N male to SMA male connections. It supports frequencies from DC to 6 GHz.
| Connections | N male to SMA male |
|---|---|
| Length | 70 cm |
| Impedance | 50 Ω |
| Frequency range | DC–6 GHz |
The cable construction is described by Siglent as RG223 coax. It is intended for RF test and measurement connections in development and manufacturing environments.
Published performance
VSWR ≤1.25 at 6 GHz
Ins. loss ≤1.8 dB at 6 GHz
Typical applications
- RF test and measurement
- Development and verification setups
- Laboratory and manufacturing test connections
See the Specification tab for the key technical data and the Documentation tab for the manufacturer datasheet, where available.
