Rigol DL3021A Programmable DC Electronic Load 150V, 40A, 200W

(1 customer review)

£524.00 (£628.80 inc. VAT)

1 in stock (can be backordered)

Availability: Stock models delivered next working day (UK only) for orders placed before 16:30 (Mon - Fri)

SKU: DL3021A Categories: , Brand:

Description


Rigol DL3021A Electronic Load

The DL3021A is a Single Input 40A, 150V, 200W DC Electronic Load. The Rigol DL3000’s are a series of high performance and cost-effective programmable DC Electronic Loads. With a user-friendly interface and superb performance specifications, the DL3000 series provides various interfaces for remote communication to meet your diversified test requirements. It can be widely used in various industries, such as automotive electronics, aerospace, and fuel cells.

Product Images

30kHz Dynamic Mode

3 Built in application setups for battery testing or Current or Power optimisation

High resolution and accuracy on voltage and current load conditions

Free UltraLoad Software for remote operation and monitoring

Dynamic Load Performance and Visualisation

×

Documentation


SpecificationDL3021DL3021ADL3031DL3031ADL3041
DC Input (0°C – 40°C)
Voltage0–150 V0–150 V0–200 V
Current0–40 A0–60 A0–70 A
Maximum Power200 W350 W450 W
Minimum Operating Voltage (0°C–40°C)1 V@40 A1.3 V@60 A1.5 V@70 A
Stability[9]
Current Stability±(0.01%+10 mA)
Voltage Stability±(0.01%+10 mV)
CC Mode
CC Range0–4 A0–6 A0–7 A
CC Programmable Resolution1 mA
CC Programmable Accuracy[1]±(0.1%+0.1%FS[3])±(0.05%+0.05%FS)±(0.1%+0.1%FS)±(0.05%+0.05%FS)
CC Temperature Coefficient[2]100 ppm/°C
CV Mode[4]
CV Range0–15 V / 0–150 V0–15 V / 0–150 V0–150 V0–150 V0–25 V / 0–200 V
CV Programmable Resolution1 mV / 1 mV5 mV / 5 mV1 mV5 mV1 mV / 5 mV
CV Programmable Accuracy±(0.1%+0.02%FS)±(0.05%+0.02%FS)±(0.05%+0.02%FS)±(0.05%+0.02%FS)±(0.05%+0.025%FS) (Both Ranges)
CV Temperature Coefficient50 ppm/°C
CR Mode[6]
CR Range[6]0.08 Ω–15 kΩ (0.0667 S–12.5 S)
2 Ω–15 kΩ (0.0000667 S–0.5 S)
CR Programmable Resolution2 mA/Vsense
CR Programmable Accuracy[7]Vin/Rset*(0.2%)+0.2%IFS
CP Mode[5] (Max. Power)
CP Range0–200 W0–350 W0–450 W
CP Resolution100 mW
Con Mode
Frequency Range0.001 Hz–15 kHz
0.001 Hz–30 kHz		0.001 Hz–30 kHz
Frequency Resolution0.8%
Frequency Accuracy±0.5%
Duty Cycle Range5%–95%, 1%
Current Slew Rate[8]
Slew Rate Range0.001 μs–1 A/μs0.001 μs–5 A/μs
Slew Rate Resolution0.001 A/μs
Slew Rate Accuracy5%+10 μs
Readback Current
Current Readback Range0–40 A0–60 A0–70 A
Current Readback Resolution1 mA0.1 mA1 mA0.1 mA
Current Readback Accuracy±(0.1%+0.1%FS)±(0.05%+0.05%FS)±(0.1%+0.1%FS)±(0.05%+0.05%FS)
Current Readback Temp. Coeff.[2]50 ppm/°C
Readback Voltage
Voltage Readback Range0–150 V0–200 V
Voltage Readback Resolution0.1 mV
Voltage Readback Accuracy±(0.1%+0.02%FS)±(0.05%+0.02%FS)
Voltage Readback Temp. Coeff.[2]20 ppm/°C
Readback Resistance
Resistance Readback Range0.08 Ω–15 kΩ (0.0000667 S–12.5 S)
Resistance Readback Resolution2 mA/Vsense
Readback Power
Power Readback Range0–200 W0–350 W0–450 W
Power Readback Resolution100 mW
Protection Function
Overcurrent protection (OCP), overvoltage protection (OVP), overpower protection (OPP), overtemperature protection (OTP), as well as local/remote reverse voltage (LRV/RRV) protection.

1 review for Rigol DL3021A Programmable DC Electronic Load 150V, 40A, 200W

  1. Paul K –

    DL3031A PROGRAMMABLE DC ELECTRONIC LOAD
    Service was spot on. Delivery was on time.

    After testing the unit for a week, I am impresses. For the price compared to my big £16,000 4kw setup the DL3031A is a superb bench-top unit and works very well.
