RF Adapter Kit
RF Adapter Set

Radio Adapter Kit





Alternative Views:


RF Adapter Kit

Our Price: £50.00 (60.00 inc VAT)





Quantity in our UK Stock.:1

Availability: Stock models DELIVERED NEXT WORKING DAY (UK only) for orders placed before 15:00 (Mon. - Fri.).
Product Code: VBLAB

Description


Selected set of RF adapters for testing a range of SMA, BNC and PL259 cables, assemblies, filters - Convenient for exploring passive devices of all kinds.

Intended for use with the DSA815-TG and with the VB1020 bridge to maximise range of testing capabilities in radio-related applications. As ever, when using these connectors, remember to ensure no energy passes from your own equipment / antenna / DUT into the DSA800 or via the VB1020 as this can damage sensitive measuring equipment.

See 'Features' for connector breakdown and details.

Features
  • Includes five selected connectors in total
  • Covers multiple combinations of device tests
  • Suitable for radio cable and passive equipment with BNC and PL259 connections
This kit contains:
  • 2-off N-type (M) to SMA (F) adapters, suited to connecting to VB or DSA input or DSA TG output
  • 1-off SMA (M) 50 Ohm termination - 1Watt abs.max rated to 6GHz
  • 1-off BNC (F) to SMA (M) adapter
  • 1-off SO239 (UHF) to SMA (M) adapter for testing passives e.g. cables with one end PL259 already fitted.
