Description
RIGOL DHO1204 12 bit, 4Ch, 200MHz, 2GSa/s High Resolution Oscilloscope
Please note: This used product has a damaged box. Unless otherwise stated, all equipment is functional at the time of testing.
The DHO1204 digital oscilloscope is designed to meet the designing, debugging, and testing requirements of the mainstream oscilloscope market. Adopting the brand-new chipset “Centaurus” developed by RIGOL, this series achieves a fast waveform capture rate of 1,500,000 wfms/s with the UltraAcquire mode, 100 Mpts memory depth, 12-bit vertical resolution, all combined with excellent noise floor performance and vertical accuracy to meet your requirements for more accurate measurements.
Ultra-low noise floor for cleaner signals, measuring small signals more accurately with high resolution of 12 bits (212=4096) to see the max signal detail.
The DHO1104 has up to 2GSa/s real-time sample rate with a high sensitivity of 500 µV vertical scale, allowing capture of small signals in the microvolt (µV) range.
It also has a wide vertical sensitivity range:500 µV/div to 10 V/div, capable of handling the smallest to the largest signals. The front-panel Flex Knobs, brings smoother interaction and easier measurements. There’s also optional battery pack in a highly portable package for you to enjoy unlimited freedom.
Features:
- Brand-new chipset “Centaurus” developed by RIGOL
- Ultra-low noise floor at 18 μVrms in minimum
- 12-bit vertical resolution[1]
- 100 MHz analogue bandwidth, 4 analogue channels, and 1 EXT channel
- Up to 2GSa/s real-time sample rate
- Max. memory depth: 100 Mpts (optional)
- Min. vertical sensitivity: 500 μV/div
- Up to 1,500,000 wfms/s waveform capture rate with the UltraAcquire mode
- 10.1” 1280*800 HD touch display
- User-friendly Flex Knobs, bringing smoother interaction
- Standard photoelectric encoder operating knobs, effectively prolonging its service life
- Standard USB Device & Host, LAN, and HDMI interfaces
- Optional battery pack in a highly portable package for unlimited freedom
- Support online version upgrade
DHO1000 Series Datasheet
