Sale!
Image of Dg831 front telonic
Image of Dg800 side telonic
Image of Dg800 rear telonic

Clearance: Rigol DG831 35MHz Single-Channel Function / Arbitrary Waveform Generator

Original price was: £306.00.Current price is: £260.00. (£312.00 inc. VAT)

3 in stock

Stock models delivered next working day (UK only) for orders placed before 16:30 (Mon - Fri)

SKU: DG831 Category: Brand:

Description


This Series has been Discontinued. Available while stocks last. Please See the New Series Here.

Rigol DG831 Function Generator

The DG831 is a 1CH, 35MHz Function Generator with a maximum sampling rate of 125MSa/s. The Rigol DG800 series offers a user-friendly and high-performance function/arbitrary waveform generator solution at a very attractive price. Each instrument provides many functions including; function generator, arbitrary waveform generator, noise source, pulse generator, harmonics generator, analogue / digital modulator and frequency counter. Any Rigol DG800 series function/arbitrary waveform generator would be a valuable asset in any home, business or education laboratory.

Features:

  • Unique SiFiII (Signal Fidelity II) technology
  • Two fully functional and independent channels (optional upgrade on single-channel models)
  • Maximum frequency 35MHz
  • 125MSa/s sample rate
  • 16-bit vertical resolution
  • Basic waveforms: Sine, square, ramp, pulse, noise, DC, dual-tone
  • Advanced waveforms: PRBS, RS232, sequence
  • 160 built-in arbitrary waveforms
  • Up to 8Mpts (optional) arbitrary waveform memory, 2Mpts standard
  • Supported modulation: AM, FM, PM, ASK, FSK, PSK & PWM
  • Intuitive arbitrary waveform editing software for PC
  • ±1ppm frequency stability
  • Phase noise <-105dBc/Hz @ 10kHz (f = 10MHz)
  • Built-in 7 digit counter up to 240MHz
  • Built-in 8th order harmonics generator
  • Waveform summing function
  • 4.3″ TFT LCD colour touch-screen display (480 x 272), 16M colours
  • Connectivity… USB Host & Device, (USB-LAN optional)
  • Standard accessories… UK & European mains leads, BNC cable (25MHz & 35MHz models only), quick guide
  • Optional accessories… 40dB attenuator, USB to LAN module
  • Other options include… Single-to-dual channel upgrade licence, memory depth upgrade (to 8Mpts) licence, Telonic Standard Calibration (traceable to UK national standards), RCL 17025 Calibration

Rigol DG800 Function Generator Comparison Table

MODELChannelsMaximum FrequencySample RateAccuracyBuilt-In WaveformsModulationConnections
DG811110MHz125MSa/s±1ppm7-off Basic,
3-off Advanced,
160-off Arbitrary		AM, FM, PM, ASK, FSK, PSK and PWMUSB Host&Device (std.)
USB-LAN (opt.)
DG812210MHz125MSa/s±1ppm7-off Basic,
3-off Advanced,
160-off Arbitrary		AM, FM, PM, ASK, FSK, PSK and PWMUSB Host&Device (std.)
USB-LAN (opt.)
DG821125MHz125MSa/s±1ppm7-off Basic,
3-off Advanced,
160-off Arbitrary		AM, FM, PM, ASK, FSK, PSK and PWMUSB Host&Device (std.)
USB-LAN (opt.)
DG822225MHz125MSa/s±1ppm7-off Basic,
3-off Advanced,
160-off Arbitrary		AM, FM, PM, ASK, FSK, PSK and PWMUSB Host&Device (std.)
USB-LAN (opt.)
DG831135MHz125MSa/s±1ppm7-off Basic,
3-off Advanced,
160-off Arbitrary		AM, FM, PM, ASK, FSK, PSK and PWMUSB Host&Device (std.)
USB-LAN (opt.)
DG832235MHz125MSa/s±1ppm7-off Basic,
3-off Advanced,
160-off Arbitrary		AM, FM, PM, ASK, FSK, PSK and PWMUSB Host&Device (std.)
USB-LAN (opt.)

Product Images

Signal Jitter As Low As 200ps

SiFi II Technology

Harmonic Generator

Fanless Silent Operation

Arb Sequencing

200MHz Hardware Counter

16Bit Vertical Resolution

4.3 Inch Touch Screen

Support Multiple Signal Outputs

×

Product Videos

YouTube Video
RIGOL's DG800 and DG900 series Arbitrary Function Generators
YouTube Video
DG800 and DG900 Series User Interface

Documentation

Datasheet

Rigol DG800 Datasheet



User Guide

Rigol DG800 User Guide



Application Notes

SiFi 2 Technology and 16 Bit Resolution App Note



SpecificationDG811DG812DG821DG822DG831DG832
Channels121212
Max. Frequency10MHz10MHz25MHz25MHz35MHz35MHz
Sample Rate125 MSa/s125 MSa/s125 MSa/s125 MSa/s125 MSa/s125 MSa/s
WaveformDG811DG812DG821DG822DG831DG832
Basic WaveformsSine, Square, Ramp, Pulse,
Noise, DC, Dual-tone		Sine, Square, Ramp, Pulse,
Noise, DC, Dual-tone		Sine, Square, Ramp, Pulse,
Noise, DC, Dual-tone		Sine, Square, Ramp, Pulse,
Noise, DC, Dual-tone		Sine, Square, Ramp, Pulse,
Noise, DC, Dual-tone		Sine, Square, Ramp, Pulse,
Noise, DC, Dual-tone
Advanced WaveformsPRBS, RS232, SequencePRBS, RS232, SequencePRBS, RS232, SequencePRBS, RS232, SequencePRBS, RS232, SequencePRBS, RS232, Sequence
Built-in Arbitrary Waveforms160 types of waveforms, including Sinc, Exponential Rise, Exponential Fall, ECG, Gauss, HaverSine, Lorentz, etc.160 types of waveforms, including Sinc, Exponential Rise, Exponential Fall, ECG, Gauss, HaverSine, Lorentz, etc.160 types of waveforms, including Sinc, Exponential Rise, Exponential Fall, ECG, Gauss, HaverSine, Lorentz, etc.160 types of waveforms, including Sinc, Exponential Rise, Exponential Fall, ECG, Gauss, HaverSine, Lorentz, etc.160 types of waveforms, including Sinc, Exponential Rise, Exponential Fall, ECG, Gauss, HaverSine, Lorentz, etc.160 types of waveforms, including Sinc, Exponential Rise, Exponential Fall, ECG, Gauss, HaverSine, Lorentz, etc.
Frequency CharacteristicsDG811DG812DG821DG822DG831DG832
Sine1 μHz to 10 MHz1 μHz to 10 MHz1 μHz to 25MHz1 μHz to 25MHz1 μHz to 35MHz1 μHz to 35MHz
Square1 μHz to 5 MHz1 μHz to 5 MHz1 μHz to 10 MHz1 μHz to 10 MHz1 μHz to 10 MHz1 μHz to 10 MHz
Ramp1 μHz to 200 kHz1 μHz to 200 kHz1 μHz to 500 kHz1 μHz to 500 kHz1 μHz to 1 MHz1 μHz to 1 MHz
Pulse1 μHz to 5 MHz1 μHz to 5 MHz1 μHz to 10 MHz1 μHz to 10 MHz1 μHz to 10 MHz1 μHz to 10 MHz
Harmonic1 μHz to 5 MHz1 μHz to 5 MHz1 μHz to 10 MHz1 μHz to 10 MHz1 μHz to 15MHz1 μHz to 15MHz
PRBS2 kbps to 10 Mbps2 kbps to 10 Mbps2 kbps to 20 Mbps2 kbps to 20 Mbps2 kbps to 30 Mbps2 kbps to 30 Mbps
Dual-Tone1 μHz to 10 MHz1 μHz to 10 MHz1 μHz to 20 MHz1 μHz to 20 MHz1 μHz to 20 MHz1 μHz to 20 MHz
RS232baud rate range: 9600, 14400, 19200, 38400, 57600, 115200, 128000, 230400baud rate range: 9600, 14400, 19200, 38400, 57600, 115200, 128000, 230400baud rate range: 9600, 14400, 19200, 38400, 57600, 115200, 128000, 230400baud rate range: 9600, 14400, 19200, 38400, 57600, 115200, 128000, 230400baud rate range: 9600, 14400, 19200, 38400, 57600, 115200, 128000, 230400baud rate range: 9600, 14400, 19200, 38400, 57600, 115200, 128000, 230400
Sequence2 k to 30 MSa/s2 k to 30 MSa/s2 k to 30 MSa/s2 k to 30 MSa/s2 k to 30 MSa/s2 k to 30 MSa/s
Noise (-3dB)100 MHz bandwidth100 MHz bandwidth100 MHz bandwidth100 MHz bandwidth100 MHz bandwidth100 MHz bandwidth
Arbitrary Waveform1 μHz to 5 MHz1 μHz to 5 MHz1 μHz to 10MHz1 μHz to 10MHz1 μHz to 10MHz1 μHz to 10MHz
Resolution1 μHz1 μHz1 μHz1 μHz1 μHz1 μHz
Accuracy±(1 ppm of the setting value + 10 pHz), 18℃ to 28℃±(1 ppm of the setting value + 10 pHz), 18℃ to 28℃±(1 ppm of the setting value + 10 pHz), 18℃ to 28℃±(1 ppm of the setting value + 10 pHz), 18℃ to 28℃±(1 ppm of the setting value + 10 pHz), 18℃ to 28℃±(1 ppm of the setting value + 10 pHz), 18℃ to 28℃
General SpecificationsDG811DG812DG821DG822DG831DG832
Power Voltage100 V to 127 V (45 Hz to 440 Hz)
100 V to 240 V (45 Hz to 65Hz)		100 V to 127 V (45 Hz to 440 Hz)
100 V to 240 V (45 Hz to 65Hz)		100 V to 127 V (45 Hz to 440 Hz)
100 V to 240 V (45 Hz to 65Hz)		100 V to 127 V (45 Hz to 440 Hz)
100 V to 240 V (45 Hz to 65Hz)		100 V to 127 V (45 Hz to 440 Hz)
100 V to 240 V (45 Hz to 65Hz)		100 V to 127 V (45 Hz to 440 Hz)
100 V to 240 V (45 Hz to 65Hz)
Power ConsumptionLower than 30 WLower than 30 WLower than 30 WLower than 30 WLower than 30 WLower than 30 W
Display4.3-inch TFT LCD touch screen4.3-inch TFT LCD touch screen4.3-inch TFT LCD touch screen4.3-inch TFT LCD touch screen4.3-inch TFT LCD touch screen4.3-inch TFT LCD touch screen
Resolution480 horizontal × RGB × 272 vertical resolution480 horizontal × RGB × 272 vertical resolution480 horizontal × RGB × 272 vertical resolution480 horizontal × RGB × 272 vertical resolution480 horizontal × RGB × 272 vertical resolution480 horizontal × RGB × 272 vertical resolution
Colour16 M16 M16 M16 M16 M16 M
Temperature RangeOperating: 0℃ to 45℃
Non-operating: -40℃ to 60℃		Operating: 0℃ to 45℃
Non-operating: -40℃ to 60℃		Operating: 0℃ to 45℃
Non-operating: -40℃ to 60℃		Operating: 0℃ to 45℃
Non-operating: -40℃ to 60℃		Operating: 0℃ to 45℃
Non-operating: -40℃ to 60℃		Operating: 0℃ to 45℃
Non-operating: -40℃ to 60℃
Cooling MethodNatural air coolingNatural air coolingNatural air coolingNatural air coolingNatural air coolingNatural air cooling
Humidity RangeBelow 30℃: ≤95%RH
30℃ to 40℃: ≤75%RH
40℃ to 50℃: ≤45%RH		Below 30℃: ≤95%RH
30℃ to 40℃: ≤75%RH
40℃ to 50℃: ≤45%RH		Below 30℃: ≤95%RH
30℃ to 40℃: ≤75%RH
40℃ to 50℃: ≤45%RH		Below 30℃: ≤95%RH
30℃ to 40℃: ≤75%RH
40℃ to 50℃: ≤45%RH		Below 30℃: ≤95%RH
30℃ to 40℃: ≤75%RH
40℃ to 50℃: ≤45%RH		Below 30℃: ≤95%RH
30℃ to 40℃: ≤75%RH
40℃ to 50℃: ≤45%RH
AltitudeOperating: below 3,000 meters
Non-operating: below 15,000 meters		Operating: below 3,000 meters
Non-operating: below 15,000 meters		Operating: below 3,000 meters
Non-operating: below 15,000 meters		Operating: below 3,000 meters
Non-operating: below 15,000 meters		Operating: below 3,000 meters
Non-operating: below 15,000 meters		Operating: below 3,000 meters
Non-operating: below 15,000 meters
Dimensions (W×H×D)237.4 mm × 97 mm × 268 mm237.4 mm × 97 mm × 268 mm237.4 mm × 97 mm × 268 mm237.4 mm × 97 mm × 268 mm237.4 mm × 97 mm × 268 mm237.4 mm × 97 mm × 268 mm
WeightPackage excluded: 1.75 kg
Package included: 2.85 kg		Package excluded: 1.75 kg
Package included: 2.85 kg		Package excluded: 1.75 kg
Package included: 2.85 kg		Package excluded: 1.75 kg
Package included: 2.85 kg		Package excluded: 1.75 kg
Package included: 2.85 kg		Package excluded: 1.75 kg
Package included: 2.85 kg
InterfaceUSB Host, USB Device, and USB-GPIBUSB Host, USB Device, and USB-GPIBUSB Host, USB Device, and USB-GPIBUSB Host, USB Device, and USB-GPIBUSB Host, USB Device, and USB-GPIBUSB Host, USB Device, and USB-GPIB
Calibration Interval1 year (recommended)1 year (recommended)1 year (recommended)1 year (recommended)1 year (recommended)1 year (recommended)

Note*

Specifications are liable to change. For the full list of Specifications, please see the products datasheet located under the ‘Documentation’ tab.
