Rental Rigol DP711 Linear DC Power Supply (30V/5A)

£67.00 (£80.40 inc. VAT)

Prices shown are weekly rental rates.

You will be charged weekly until the items are returned

Available on back-order

SKU: DP711-Demo Categories: , , , Brand:

Description


Rental Rigol DP711 DC Power Supply

The DP711 is a Single Output 30V, 5A, 150W DC Power Supply. Ideal for the hobbyist, educational establishments and businesses alike – The Rigol DP700 series power supplies are affordable, high performance, programmable linear DC power supplies. Superb performance specifications, pure and reliable output, clear user interface – The DP700 series supports timing output, trigger function and provides a remote communication interface, enabling you to meet your diversified test requirements.

Product Images

Convenient trigger function

Timing output function

OVP & OCP

×

Documentation

Rigol DP700 User Guide Rigol DP700 Specifications Rigol DP700 Datasheet Rigol DP700 Programming Guide
DC Output (0°C to 40°C)
ModelDP711DP712
Voltage/Current Rating0 V to 30 V/0 A to 5 A0 V to 50 V/0 A to 3 A
OVP/OCP0.01 V to 33 V/0.01 A to 5.5 A0.01 V to 55 V/0.01 A to 3.3 A
Load Regulation, ±(% of Output + Offset)
Voltage<0.01% + 2 mV<0.01% + 2 mV
Current<0.01% + 2 mA<0.01% + 2 mA
Line Regulation, ±(% of Output + Offset)
Voltage<0.01% + 2 mV<0.01% + 2 mV
Current<0.01% + 2 mA<0.01% + 2 mA
Ripple and Noise (20 Hz to 20 MHz)
Normal Mode Voltage<500 μVrms/3 mVpp<500 μVrms/4 mVpp
Normal Mode Current<2 mArms<2 mArms
Annual Accuracy (25°C ± 5°C), ±(% of Output + Offset)
Programming
Voltage0.05% + 20 mV0.05% + 20 mV
Current0.2% + 20 mA0.2% + 20 mA
Readback
Voltage0.05% + 20 mV0.05% + 20 mV
Current0.2% + 20 mA0.2% + 20 mA
Resolution
Programming
VoltageStandard: 10 mV
High resolution option installed: 1 mV		Standard: 10 mV
High resolution option installed: 1 mV
CurrentStandard: 10 mA
High resolution option installed: 1 mA		Standard: 10 mA
High resolution option installed: 1 mA
Readback
VoltageStandard: 10 mV
High resolution option installed: 1 mV		Standard: 10 mV
High resolution option installed: 1 mV
CurrentStandard: 10 mA
High resolution option installed: 1 mA		Standard: 10 mA
High resolution option installed: 1 mA
Display
VoltageStandard: 10 mV
High resolution option installed: 1 mV		Standard: 10 mV
High resolution option installed: 1 mV
CurrentStandard: 10 mA
High resolution option installed: 1 mA		Standard: 10 mA
High resolution option installed: 1 mA
Transient Response Time
Transient Response TimeLess than 50 μs for output voltage to recover to within 15 mV following a change in output current from full load to half load (or from
half load to full load).		Less than 50 μs for output voltage to recover to within 15 mV following a change in output current from full load to half load (or from
half load to full load).

Note* Specifications are liable to change. For the full list of Specifications, please see the products datasheet located under the ‘Documentation’ tab.
