Rigol DS6104 1GHz 4-Channel Digital Oscilloscope
Rigol DS6104 Digital Oscilloscope

Rigol DS6104





Alternative Views:


Rigol DS6104
1GHz Digital Oscilloscope

Our Price: £6,995.00 (8,394.00 inc VAT)
Latest Firmware Fitted read more





Quantity in our UK Stock.:
(Out of Stock-Click to be notified when in stock)


Availability: Usually ships in 1 to 2 weeks from receipt of order.
Product Code: DS6104



The following items are included FREE OF CHARGE with this product:

Description Specification Documents, Software & Videos


The Rigol DS6104 digital oscilloscope has a 1GHz bandwidth and optional 1.5GHz bandwidth differential and single-ended active probes (model RP7150). These new products are designed and produced by Rigol with many key technological breakthroughs designed to help engineers achieve more thorough research, development and failure analysis applications. Detecting signal and device characteristics is now easier than ever with the most advanced digital oscilloscope platform in its class. Rigol DS6000-series platforms are aimed at communications, semiconductor, computing, aerospace, defence, instrumentation, research/education, industrial electronics, consumer electronics and automotive industries. The Rigol DS6000 is the oscilloscope of choice for innovative technology teams with industry leading specifications, broad analysis capabilities and the most powerful trigger functions and display capabilities.

For further information, please refer to the 'SPECIFICATION' and 'DOCUMENTS, SOFTWARE & VIDEOS' tabs, above.

An overview of all Rigol digital oscilloscopes can be found HERE.



Click image to enlarge

Features
  • 1GHz bandwidth, 4 channels
  • Maximum sample rate 5GSa/s
  • Vertical scale 2mV/div to 5V/div
  • Selectable 50Ω input impedance
  • Memory depth up to 140Mpts per channel
  • Innovative "UltraVision" technology
  • Up to 180,000wfms/s waveform capture rate
  • Up to 200,000 frames real-time waveform record, replay & analysis functions
  • A variety of trigger functions
  • Automatic measurements with statistics
  • 10" WVGA (800x480) TFT LCD display, 256 intensity grading levels
  • Connectivity: USB Host & Device, LAN(LXI), AUX Output, (USB-GPIB, optional)
  • VGA output for display on large screens
  • Supplied with... 4-off passive probes (600MHz), 2-off low-Z passive probes (1.5GHz), USB cable, UK & European mains leads, front panel cover, quick guide
  • Options include... Active probe (1.5GHz), active differential probe (1.5GHz), Tektronix TekProbe® interface adapter, desk mount instrument arm, rack mount kit, USB to GPIB module, RS232/UART decoding kit, I2C/SPI decoding kit, CAN decoding kit, FlexRay decoding kit, RCL standard calibration, RCL UKAS calibration
