Rigol DS4034 350MHz 4-Channel Digital Oscilloscope
Rigol DS4034 Digital Oscilloscope

Rigol DS4034





Alternative Views:


Rigol DS4034
350MHz Digital Oscilloscope

Our Price: £4,454.00 (5,344.80 inc VAT)
Latest Firmware Fitted read more





Quantity in our UK Stock.:
(Out of Stock-Click to be notified when in stock)


Availability: Usually ships in 1 to 2 weeks from receipt of order.
Product Code: DS4034



The following items are included FREE OF CHARGE with this product:

Description Specification Documents, Software & Videos


The DS4034 is a versatile, high performance digital oscilloscope. It offers a variety of trigger functions and auto measurements, record / playback / analysis functions, selectable 50Ω input impedance and VGA output all as standard. Other standard features include a waveform capture rate up to 110,000wfms/s and a large 9" WVGA display with 256 intensity level grading. The DS4034 is a flexible and powerful instrument at a very competitive price.

For further information, please refer to the 'SPECIFICATION' and 'DOCUMENTS, SOFTWARE & VIDEOS' tabs, above.

An overview of all Rigol digital oscilloscopes can be found HERE.

This Rigol oscilloscope is also available with a built-in logic analyser (MSO4034).



Click image to enlarge

Features
  • 350MHz bandwidth, 4 channels
  • Maximum sample rate 4GSa/s
  • Vertical scale 1mV/div to 5V/div
  • Selectable 50Ω input impedance
  • Memory depth up to 70Mpts per channel
  • Innovative "UltraVision" technology
  • Up to 110,000wfms/s waveform capture rate
  • Up to 200,000 frames real-time waveform record, replay & analysis functions
  • A variety of trigger functions
  • Automatic measurements with statistics
  • 9" WVGA (800x480) TFT LCD display, 256 intensity grading levels
  • Connectivity: USB Host & Device, LAN(LXI), AUX Output, (USB-GPIB, Optional)
  • VGA output for display on large screens
  • Supplied with... 4-off passive probes (500MHz), USB cable, UK & European mains leads, front panel cover, quick guide
  • Options include... High-voltage probes, high-voltage differential probes, current probes, Tektronix TekProbe® interface adapter, calibration kit, rack mount kit, RS232/UART decoding, I2C/SPI decoding, CAN/LIN decoding, FlexRay decoding, standard calibration (traceable to UK national standards), UKAS calibration
